Product Description
Family friendly and flexible
Transformed in no time at all - perfect for children's transport or as a load e-bike. Safe for two children: Specially designed for the stable and comfortable transport of your loved ones.
High load capacity and practical tested
Up to 200 kg total load – ideal for bulk shopping, sports equipment or weekend trips. - Division: 150 kg (the driver) + 20 kg (front basket) + 100 kg (rear rack). - Everyday use: Rugged design for reliable performance on every ride.
Dual battery: up to 140 km range
Two 48 V 12 Ah batteries: intelligent balancing system for even discharge and maximum efficiency. - Over 100 km range: Perfect for longer trips or multi-day use without charging. - Quick Charge: Each battery is fully charged in just 4.5 hours – removable for flexible charging options.
Smart support 75 NM drive
250 W hub motor and torque sensor: feel a smooth pedal assist experience, especially on inclines and when starting. -Up to 75 Nm torque: Powerful and legally safe. - Three levels of support: Easy to use with thumb switch on the clear LCD display.
Comfort and stability at any load: double suspension
front suspension fork and rear suspension seat post for a smooth ride – even on uneven roads. - Relieved back: Less fatigue on long distances.
Safety in any weather
hydraulic disc brakes: front and rear for strong braking performance in rain, mud or slopes. - All-weather tyre 20 x 3.0 inch fat tyres for excellent grip on cobblestones, gravel, sand and even snow.
Space-saving and fully equipped
lightweight aluminium frame: rust-proof, durable and with folding handlebar for space-saving storage. - Standard accessories: Includes front and rear lights, mudguards, footrests and a sturdy central stand. - Gift Box: Includes replacement brake pads, hose, valve caps, tool kit and key chain.
Specification:
Brand:FAFREES
MODEL:FF20 CUV
Type:Family Longtail E-Cargo Bike
Frame material:Aluminum alloy
Tire size:20"*3.0
Tire Type:Air tire
Default maximum speed:25km/h
Max range for assisted mode:100-140km
Max climbing Gradability:20°
Battery type:18650 Lithium-ion battery
Rated voltage:48V
Input voltage:54.6V
Battery capacity:12Ah 576Wh*2
Motor:250W Rear drive
Maximum torque:75N.m
Charger Input voltage:110-240V
Output voltage:54.6V
Rated current:3A
Charging time:4.5h*2
Fork Type:Shock fork
Type of rear shock:Seat shock tube
Display type:LCD
PAS level:0-3
Speed Sensor:Torque Sensor
Brake type:Hydraulic disc brakes
Headlight:Yes
Taillight:Yes
Operating temperature: （-20）℃-40℃
Waterproof grade:IPX5
Net Weight:38kg
Package weigh:47.8kg
Battery weight:3.1+3.1kg
Load capacity:200kg
Front basket size:36*32*16cm
Rear child passenger seat size:72.5*42.5*21cm
Recommend rider heights:160-200cm
Product size:190*67*120cm
Package size:164*29*76cm
