Main features
384 × 288 resolution with @12 μm thermal sensor
High-sensitivity NETD thermal detector < 20 mK (@25°C, F# = 1.0)
35 mm F1.0 lens with detection range up to 1,800 m
High-resolution 2,560 × 1,440 CMOS sensor
35 mm F2.2 digital lens with x2.9 - x23.2 digital zoom
0.49-inch OLED screen with 1,920 x 1,080 resolution
Integrated 940 nm IR lamp
Precision laser range finder (±1 m) with distance measurement up to 1,000 m
Light weight of 780 g
Optical module
Image sensor: 1.88"" progressive-scan CMOS
Max. resolution: 2,560 × 1,440
Focal length: 35 mm
Aperture: F1.2
Image enhancement: Yes
Min. focus distance. : 3 m
Magnification: 2.9 - 23.2
Field of view (H × V), Degrees/m @100 m: 13.9 × 7.8 / 24.4 m × 13.6 m @ 100 m
Smart IR: Yes
Illuminator wavelength: 940 nm
Night vision range: 350 m
Thermal module
Sensor : VOx uncooled focal plane arrays
Resolution: 384 × 288
Frame rate: 50 hz
No pixel: 12 μm
Spectral band: 8 µm – 14 µm
NETD: < 20 mk (@25°C, F# = 1.0)
Lens (focal length): 35 mm
Aperture: F 1.0
Digital zoom: 1 ×, 2 ×, 4 ×, 8 ×
Magnification: 4.0 - 32.0 (x8 zoom)
Detection range: 1800 m
Min. setting distance. 3.5 m
Focus mode: Manual
Field of view (h × v), degrees/m @100 m: 7.5° × 5.7° (H × V)/ 13.2 m × 9.9 m @ 100 m
Laser rangefinder
"Laser safety class: Class 1
Wave length: 905 nm
Max. measurement range: 1000 m
Accuracy of measurement: ± 1 m
Min. measurement distance: 10 m"
Screen
DISPLAY: 0.49 inch, OLED, 1920 × 1080
Pallets: Thermal Warm White, Warm Black, Warm Red, Fusion / Optical: Day, Night, Auto
FFC mode FLAT FIELD CORRECTION): Auto, Manual, External correction
Exit pupil: 8 mm
Eye relief: 15 mm
Dioptery: -5 D to +3 D
Brightness adjustment: Yes
Tone adjustment: Cold, warm
Contrast adjustment: Yes
Image pro: Yes
Zoom pro: Yes
System
Built-in memory: 64 GB
Video recording: Yes
Photo recording: Yes
Audio recording: Yes
Standby mode: Yes
PIP: Yes
Hotspot: Yes
Follow the hot point: Yes
GPS: Yes
Digital magnetic compass: Yes
Local album: Yes
Power source
Battery type: replaceable and rechargeable Li-ion battery
Battery operating time: 6 hours continuous operation with hotspot function deactivated (@25°C)
Type-C power supply: Yes
General
Protection level: IP67
Dimensions: 138 mm × 68.2 mm × 212 mm
Weight: 780 g without battery
Working temperature: -30°C to 55°C
Interpupillary adjustment range / 60 mm to 70 mm
Mounting adaptor: 1/4’’-20 UNC
