Product Description
Developed specifically to perform on EWS specials as well as on your favourite trails, the Deemax ENDURO combines the most advanced technologies from Mavic to challenge you with complete confidence. Available in 29'', 27.5' and Mullet.
Main Features
Ultra-responsive handling
The ISM4D construction lightens the rim without compromising its strength
The ID360 hub with Ratchet will be your best ally in acceleration zones.
The welded rim of 30mm (internal width) offers more control and comfort
Race-ready
The Fore technologies and Infinity hubs allow for quick replacement of a broken spoke mid-ride, without needing to remove the tire or rim tape.
Tubeless compatibility without rim tape (Fore technology) and an expanded bead shape allows for ultra-simplified tire changes and ensures perfect and lasting sealing
Tested and approved by our most demanding athletes
Ride confidently on rough terrains
The widened welded rim (30 mm internal) is designed to absorb the most severe impacts.
The widened rim shape makes it easier to fit DH casing tires ranging from 2.0'' to 3.0'', allowing riders to choose their preferred setup.
The double surface protection of the rims (Blackshield) preserves the aesthetic condition of the rim against stone impacts.
Specifications
Weight
Pair Weight: 1930 g
Rear Weight: 1010 g
Rim
Material: Maxtal
Height: 22 mm
Joint: SUP welding technique
Internal width: 30 mm
Drilling: Tubeless Fore technology without rim tape (front/rear 28 holes)
Braking: disc
Profile: asymmetric
ETRTO Size: 622/584x30TC
Tire: UST Tubeless Ready
Spokes
Material: steel
Shape: straight, extra-flat, tapered, anti-rotation (rear)
Nuts: brass, black
Screws: M7
Spoke lacing: crossed by 3 (front and rear)
Hubs
Body material: aluminium
Body design: INFINITY
Disc standard: 6 holes only
Axle material: aluminium
Axle size: rear 12x148
Freewheel technology: Instant Drive 360
Freewheel: Shimano MS / Sram XD MTB
Bearing technology: QRM automatic adjustment - sealed cartridge
Compatibility
Freehub body: convertible SHIMANO HG MTB aluminium (kit V3780101 sold separately)
Freehub body: convertible SHIMANO HG MTB steel (kit V3790101 sold separately)
Rear axle adapters: 12x148 convertible to 9x141 (kit V2510801 sold separately)
Included
User guide
UST valve not mounted on the wheel
2 spare spokes
2 multifunction adjustment keys with the rear wheel
Intended use
Minimum tire size: width 52mm - max pressure 2.95Bar/43PSI
Maximum tire size: width 76mm - max pressure 2.45Bar/36PSI
ASTM category 5: gravity riding focused on downhill
Maximum weight supported by the wheels: must not exceed 150 Kg (including bike weight)
