Product Description
The TTGO F6Boost is a premium electric bike designed for riding on all types of terrain. Among its key features are its extra-wide 20-inch (4.0) tires, which are particularly robust. Wider than traditional bicycle tires, they offer not only a more assertive
look but also significantly improved stability and grip.
The 20-inch (4.0) Cheng Shin tires benefit from an increased contact patch, thus optimizing grip and ensuring excellent control on sand, snow, gravel, and slippery roads. Whether tackling the complex road conditions of urban commutes or enjoying easy
off-road rides, the F6Boost adapts to all situations, making it a truly versatile bike.
Furthermore, the tire width provides excellent shock absorption. Combined with the front fork with lockout, they effectively absorb vibrations and impacts from the ground, considerably improving riding comfort. Even on long rides, fatigue from uneven
terrain is reduced, resulting in smoother and more enjoyable journeys.
In terms of motorization, the TTGO F6Boost is equipped with a 48V, 250W rear motor delivering a maximum torque of 70 Nm. Combined with a torque sensor, it guarantees responsive and smooth assistance, even on rough or loose surfaces. Its high-capacity
48V, 18Ah battery offers a range of approximately 120 kilometers, ideal for long distances.
Furthermore, the bike features a 7-speed Shimano drivetrain and high-performance hydraulic brakes, ensuring precise steering and safe braking. The LCD screen displays real-time riding data. Its maximum speed of 25 km/h complies with European standards.
Thanks to its optimized design and wide tires, the TTGO F6Boost improves stability and riding comfort, pushing the boundaries of cycling and blurring the lines between city and Life.
Frame: 6061 Aluminum Alloy, 20 inches
Fork: Suspension fork with lockout
Tires: 20 inches x 4.0 CST
Brakes: Hydraulic disc brakes
Derailleur: Shimano 7-speed
Battery: 48V 18Ah
Motor: 48V 250W rear motor
Effective Torque* (N.m): 70 Nm
Sensor: Torque
Display: LCD
Charger: 54.6V 3A
Speed: 25 km/h
Range: 150 km
Carton Dimensions: 141 x 30 x 67 cm
Net/Gross Weight: 33.5 kg/40.8 kg
Maximum Load: 150 kg
