Product Description
Product Introduction
FAFREES F20 X-Max is a folding wide tire electric bicycle that focuses on ultra long endurance and ultimate comfort. It features a high-strength steel frame and is designed specifically for riders in the 165-210cm range. Integrating a large capacity battery, powerful motor, and triple shock absorption configuration, it balances folding convenience, power performance, and riding safety, and is suitable for urban commuting, medium to long distance short distance travel. It is a high-performance and highly practical commuting equipment.
Easy to fold and widely adaptable
Adopting a folding design, the product size is 186 * 126 * 63cm, and after folding, it is only 105 * 45 * 76cm. The packaging size is 106 * 47 * 78cm, which is convenient for storage and vehicle transportation. The handlebar and seat cushion can be flexibly adjusted, with a handlebar height of 116-132cm and a seat cushion height of 86-106cm. The distance between the foot and the ground is 10cm, and the maximum load-bearing capacity is 150kg, suitable for most people. The high-strength steel frame is sturdy and durable, ensuring cycling stability.
Dual endurance mode, top-notch endurance
Equipped with a 48V 30Ah high-capacity battery, the pure electric mode has a range of 120-140km and the power assisted mode has a range of 180-200km. The charging time is only 9 hours, completely eliminating range anxiety and easily meeting long-distance travel needs. Rear drive with a maximum torque of 65 Nm, default top speed of 25 km/h, maximum climbing angle of 25 °, smooth starting, sufficient power, suitable for various road conditions and slopes.
Triple shock absorption, comfortable riding
Equipped with a shock-absorbing front fork (with a stroke of 50mm), rear shock absorbers, and shock-absorbing seat tubes, the triple shock absorption combination can efficiently filter out road bumps, greatly improving riding comfort and reducing fatigue even after long-term riding. 20 * 4.0-inch wide inflatable tires have strong grip and are suitable for various road surfaces, further enhancing riding stability and adapting to urban and mildly complex road conditions.
Professional configuration, safe and worry free
Equipped with the Ximano 7-speed transmission system, the gear shifts smoothly and accurately, and can flexibly adapt to different riding speeds and road conditions. Hydraulic disc brake has strong and sensitive braking, excellent heat dissipation, and can quickly and smoothly stop, ensuring riding safety; IPX4 waterproof rating can withstand daily water damage and protect core components. The net weight of the vehicle is 49kg, the packaging weight is 55kg, and the battery weight is 7.5kg. It is easy to operate and balances performance and practicality.
[Product Parameters]
Model: FAFREES F20 X-Max
Model: Folding wide tire electric bicycle
Product size: 186 * 126 * 63 centimeters
Folding size: 105 * 45 * 76 centimeters
Packaging size: 106 * 47 * 78 centimeters
Tire size: 20 * 4.0 inches
Recommended riding height: 165-210 centimeters
Net weight: 49 kilograms
Packaging weight: 55 kilograms
Maximum load capacity: 150 kilograms
Frame material: high-strength steel
Default maximum speed: 25 kilometers per hour
Maximum range of assist mode: 180-200 kilometers
Maximum range in pure electric mode: 120-140 kilometers
Maximum climbing angle: 25 °
Battery: 48V 30Ah
Maximum torque: 65 Nm
Charging time: 9 hours
Transmission system: Ximano 7-speed
Brake type: hydraulic disc brake
Waterproof rating: IPX4
