Product Description
Product Features
- 2-in-1 pulley-carabiner combining high-performance pulley and automatic locking Triact-Lock carabiner for use in height work.
- Finger opening opposite the pulley for easy installation on anchors and devices, ideal for deviations and pulley systems.
- Sealed ball bearing sheave ensuring high efficiency (85-95%) and smooth rotation even in demanding conditions.
- H-profile carabiner providing an excellent strength-to-weight ratio and protecting markings from abrasion.
- Certified aluminum construction compliant with CE EN 362, EN 12278, UKCA, and EAC standards with high strengths (20 kN major axis, 8 kN minor axis, 7 kN open gate).
Design and Materials
The Rollclip Z Triact-Lock is made of lightweight and durable aluminum, with an H-profile optimized to reduce weight while maintaining high mechanical strength. Markings are protected against abrasion for better durability.
Pulley Performance
The pulley features a sealed ball bearing sheave offering high efficiency (up to 95% depending on configuration) and smooth rotation. Sheave diameter: 38 mm (or 18 mm according to supplier specifications), compatible with rope diameters of 7 to 13 mm.
Carabiner Features and Safety
The carabiner has a finger opening on the side opposite the pulley for easy installation on anchors and devices. Keylock system to prevent accidental snagging and automatic locking Triact-Lock ensuring secure closure; a Screw-Lock version is also available.
Capacities and Standards
Maximum indicated working load: 4 kN (2 kN x 2 kN). Strengths: 20 kN major axis, 8 kN minor axis, 7 kN open gate. Certification: CE EN 362, EN 12278, UKCA, EAC.
Recommended Applications
Designed for rope work, pruning, short ascents, deviations, and pulley systems. Ideal for professionals seeking a compact solution combining connection and high-performance pulley.
