Technical features
Travel: 100 mm
1-1/8"-1.5" tapered steerer tube
Brakes: disc
Caliper standard: PM
Axle: 15x110 mm boost
Wheel size: 29"
Lockout: yes, on the handlebar
Type of damping: Motion Control
Rebound adjustment: yes
Spring: air
Offset: 51 mm (29")
Weight: 1729 g
Max tyre width: 81 mm
Distance from axle to T: 506 mm
Care tips
In the interest of performance, safety, and keeping your fork working for as long as possible, we recommend regularly checking it over, making sure the axle and wheel are screwed on tightly, and servicing it as recommended by the manufacturer. If you need help, our workshops are at your service and offer great prices on all bike servicing jobs.
Assembly instructions
Remember to use a new star nut in your fork. When cutting the steerer tube, use a pipe cutter or a guide to get a straight cut. For your safety, we recommend having no more than 30 mm of spacers under your stem.
