Product Description
Powerful Motor and Long-Lasting Battery
The F20 pairs a 250W brushless motor with a removable 48V 15Ah Panasonic lithium battery, giving you up to 90 km of range on a single charge. The motor pulls strongly on hills and delivers smooth, steady acceleration through city streets and country lanes alike. A full charge takes six to eight hours, so you can plug in at the office or overnight at home and be ready for the next day.
Front Suspension for a Steady Ride
A premium shock-absorbing front fork takes the sting out of rough roads and gravel paths. It keeps the front wheel planted and the handlebar steady, giving you a stable, sure-footed ride even when the tarmac turns uneven. Whether you are tackling cobblestones or light off‑road trails, the suspension helps you keep your line without jarring your hands.
Step‑Through Frame for Easy Mounting
The unisex step‑through frame makes getting on and off the bike effortless. There is no high top tube to swing your leg over, so you can step right through and go. This design is especially friendly for city riders, women, and anyone who prefers a relaxed, upright position when wearing everyday clothes.
Smart APP and Clear LED Display
A 4.5‑inch colour LED screen puts speed, battery level, distance, and assist mode right in front of you. The display stays readable even in bright sunlight. Bluetooth links the bike to a dedicated app that records your ride data in real time, no network or data plan needed.
Shimano 7‑Speed Drivetrain
Seven well‑spaced gears give you the range to spin up steep hills or cruise on flat roads without draining the battery. The Shimano shifter clicks through ratios cleanly and responds quickly, so you can adapt to changing terrain with a flick of your finger.
180mm Dual Disc Brakes and Fat Tires
Front and rear mechanical disc brakes deliver strong, predictable stopping power in wet or dry weather. The 20 x 3.0‑inch fat tires provide a huge footprint, giving you grip on pavement, sand, gravel, and snow. They soak up bumps and add an extra layer of cushioning to every ride.
Specification
Brand: Bodywel
Model: F20
Battery: 48V 15Ah Panasonic 21700 Lithium Battery
Motor: 250W Brushless Geared Motor
Max Range: 90 km
Max Speed: 25 km/h
Tires: 20 x 3.0 inch CST Tires
Max Load: 120 kg
Suspension: Adjustable hydraulic shock front fork
Brake: 180 mm Dual Mechanical Disc Brakes
Drivetrain: Shimano 7‑Speed
Display: 4.5‑inch LED Color APP Display
Sensor: Speed Sensor
Charger: 54.6V 2A, Input voltage 100‑240V
Charging Time: 6‑8 h
Pedal Assist Levels: 5 levels
Riding Modes: Pedal, Pedal Assist, Pure Electric
Motor Drive: Rear Drive
Battery Type: Removable
Lights: Front LED Headlight & Rear Light
Fenders: PVC Plastic Mudguards
Rear Rack: Included
Waterproof: IPX5
Net Weight: 31.5 kg
Gross Weight: 37.2 kg
Product Size: 163 x 75 x 110 cm
Package Size: 135 x 26 x 68 cm
Handlebar Height: 110 cm
Saddle Height: 85‑105 cm
Suitable Height: 160 cm+
Max Load: 120 kg
Package Contents
1 × Bodywel F20 Electric Bike
1 × Battery Charger
1 × Tool Kit
1 × Air Pump
1 × Instructions
