Product Description
[Vehicle positioning]
TTGO E-SUVO is an electric bicycle with 27.5 x 2.4 inch tires. 6061 aluminum alloy soft tail frame, rear wheel motor drive, torque sensor provides assistance. The height of the riser can be adjusted to accommodate different heights. The net weight of the vehicle is 29kg, the gross weight of the packaging is 38kg, and the dimensions of the cardboard box are 158 × 24 × 76cm. The maximum load-bearing capacity is 125kg.
[Battery and Range]
The battery specification is 48V 15Ah, with a capacity of 720Wh, equipped with a 54.6V 3A charger, and can be fully charged in about 5-6 hours per charge. Tested range in assist mode is 100-120 kilometers, which is affected by the rider's weight, road conditions, and remaining battery life. The maximum speed is 25km/h.
[Power and Climbing]
The rated power of the rear motor is 250W, with a maximum torque of 70N. m. The maximum climbing angle is not specified, and the 70N. m torque is relatively high among vehicles in the same class, providing sufficient power for starting and uphill driving. Equipped with Shimano 7-speed mechanical transmission, downshifting on uphill is effortless, while upshifting on level roads increases speed. The instrument is equipped with an LCD display, which allows for clear viewing of information such as speed, battery level, and gear position.
[Shock absorption and braking]
The frame is designed with a soft tail, and the rear wheels are equipped with shock absorbers to enhance the comfort of bumpy roads. The front fork is a shock-absorbing fork that filters out road vibrations. Front and rear hydraulic disc brakes have strong braking force, linear feel, and reliable performance on wet and slippery roads. 27.5 × 2.4-inch tires balance passability and rolling efficiency, combined with soft tail suspension, suitable for urban commuting and mild off-road driving.
[Tire and Size]
The tires are new 27.5 × 2.4 inch inflatable tires with good grip. The soft tail frame, combined with front and rear suspension, enhances the comfort of riding on complex road conditions. Adjustable riser design, suitable for riders of different heights. The overall size of the vehicle is moderate, the packaging volume is compact, and it is convenient for storage and transportation.
[Product Parameters]
Model: TTGO E-SUVO
Frame: 27.5 "aluminum alloy soft tail with suspension, 6061
Front fork: shock absorption
Zhengxin tires: 27.5 " 2.4
Brake: oil brake
Transmission: Shimano 7s
Riser: Adjustable
Battery: 48V15AH
Motor: 48V250W rear motor,
Torque: 70NM
Sensor: Torque
Instrument: LCD
Charger: 54.6V3A
Speed: 25KM/H
Assisted driving range: 100-120KM
Carton size: 158 24 * 76cm
Net weight/gross weight: 29KGS/38KGS
Maximum load-bearing capacity: 125kg
