In a nutshell
Weight: 24 kg (in size M, without pedals)
Mid-drive motor: Brose T aluminium 70 Nm
Battery: 630 Wh
Connectivity: Decathlon Ride mobile application
Frame material: Aluminium
Type: Hardtail
Wheel size: 29"
Fork travel: 130 mm
Drivetrain: 1x10
Brakes: Hydraulic
Seat post: telescoping
Frame, handlebar and stem warranty: lifetime
Motor
BROSE DRIVE T Aluminium motor
Mid-drive position
70 Nm torque
Torque sensor
Max assistance: 320 %
Max power: 460 W
In accordance with EU regulations, the electrical assistance cuts out above 25 km/h
Battery
Battery fully integrated into the frame with side outlet for easy gripping.
Capacity: 630 Wh
Display
ERGO 900
TFT colour screen,
5 assistance modes: 1,2,3,4
Pedestrian mode assists with walking.
Connected via Bluetooth.
The control unit is installed on the left side and tilted downwards, for better ergonomics when changing modes and for maximum protection in the event of a fall or rollover.
Connectivity
Download the Decathlon Mobility app and turn your smartphone into a smart dashboard with live tracking and Auto Mode.Review the history and battery usage of your rides after you’ve finished, and manage your bike’s maintenance with ease (tutorials, workshop appointments, updates and insurance).
Weight
S: 23.9 kg
M: 24 kg
L: 24.2 kg
XL: 24.4 kg
Net weight without pedals
Frame
Frame made of 6061 aluminium
Fully built-in battery, with side outlet
Tapered steering socket
31.6 mm diameter seatpost
2-bottle cage mount
TRANSMISSION
Microshift ADVENT X
Chainring: 34 teeth with chain guide
Rear derailleur: Microshift ADVENT X
Crank: 170 mm
Right shifter: Microshift ADVENT X
Cassette: MICROSHIFT ADVENT X Series H 11-48
Chain: KMC e10S
SUSPENSION
X-Fusion RC32 29” fork
Travel: 130 mm
Dampers: 32 mm
Axle: Thru axle
Format: Boost 110x15
Offset: 51 mm
Technology: Air with RC Damper cartridge
Adjustments: compression, bounce, air pressure
WHEELSET
Rockrider 29” 30c wheels
29" size compatible with fat tyres: up to 2.6"
Internal width between hooks: 30 mm
32 spokes
Format: Boost
Discs: 6 holes
Freewheel hub: HG
Sealed bearings
Tubeless Ready, with a sealed rim strip (requires TUBELESS tyres, Presta valves, and tyre sealant)
BRAKES
Tektro M530 hydraulic disc brakes
Number of pistons: 4
Front disc: 180 mm
Rear disc: 180 mm
6-bolt mounting
RIDING POSITION
Rockrider Sport handlebar
Material: Aluminium
Diameter: 31.8 mm
Width: 740 mm (S, Ms) 760 mm (L, XL)
Rise: 10 (S, M), 25 (L, XL)
Upsweep: 0° (S, M), 6° (L, XL)
Backsweep: 9°
Rockrider stem
Material: Aluminium
Angle: 7°
Sizes: 50 mm (S), 60 mm (Ms / L), 70 mm (XL)
Grips:
Rockrider Ergo Lock On
Headset
ZS 44/28.6 - 56/40
Saddle & seat post
Saddle: Decathlon long distance 60°
Telescoping seat post: Rockrider Dropper
Diameter: 31.6 mm
Travel: 120 mm (S) / 150 mm (Ms/L) / 170 mm (XL)
Weight: from 650 g
Seat clamp: aluminium, 34.9 mm diameter
TYRE
Rockrider Grip 500
29" x 2.4"
Tubeless ready
Bead: soft
Carcass: 60 TPI 1 ply
Sidewalls: Skinwall with puncture-resistant side strip
Tread: Dual lug
Pedals
Rockrider Flat Evo Resin
ACCESSORIES INCLUDED
Your MTB comes with:
4A charger
bell,
lights,
wheel reflectors
and pedals.
