In a nutshell
Weight: 14.6 kg (in size M without pedals)
Frame material: Aluminium
Type: Full suspension
Wheel size: 29"
Fork and shock travel: 120/120 mm
Drive train: 1x10
Brakes: hydraulic disc
Seatpost:
Telescopic
Lifetime warranty on frame / 2 years for parts
Weight
S: 14.5 kg
M: 14.6 kg
L: 14.7 kg
XL: 14.9 kg
Net weight without pedals
Frame
Composition: Aluminium
Travel: 120 mm Front / Rear
Rear axle: 9x135 mm
Type of axle: Quick Release
Bottom bracket: BSA 73
Seat tube diameter: 31.6 mm
Bottle cage mount: yes (1 bottle)
Drivetrain
Microshift adventix transmission
Single chainring: 30 teeth.
Cranks: 170 mm
Rear derailleur: 10 speeds
Cassette: 11-48
"KMC E10 sport" chain: 116 links.
SUSPENSION
Fork: X-Fusion RC32
Travel: 120 mm
Dampers: 32 mm
Axle: Quick Release
Format: 15x110 mm
Shock absorber: X-Fusion O2 Pro
Format: 190x51 mm
Combolock handlebar lock, 2 positions
WHEELSET
Rockrider 29"
Inner width:23 mm
Number of spokes: 32
Disc mount: 6 holes
Freewheel hub: Standard Shimano HG
Axle types: 15 X 110 mm thru axle (front) and quick release 9 x 135 mm (rear) Tubeless Ready:Yes
Equipped with watertight rim tape:Yes
Brakes
Hydraulic disc brakes
Tektro M276
Number of pistons: 2
Front disc: 180 mm
Rear disc: 160 mm
Disc mount: 6 bolts
Riding position
Handlebar: Rockrider
Material: Aluminium
Diameter: 31.8 mm
Width: 740 mm
Stem: Rockrider
Material: Aluminium
Angle: 7°
Sizes: 60 mm
Grips:
Sport 900 Confort
Saddle & seat post
Saddle: Rocker MTB 60°
Seatpost: Rockrider
Material: Aluminium
Diameter: 31.6 mm
Length: 100 mm (S), 125 mm (M), 150 mm (L), 170 mm (XL)
Tires
Front tyre: Vittoria Barzo 29x2,2
Rear tyre: Vittoria Barzo 29x2,2
Tubeless Ready: Yes
Pedals
Btwin Sport 520 Grip flat pedals
Material:resin
ACCESSORIES INCLUDED
Your MTB comes with:
bell,
lights,
wheel reflectors
and pedals.
