/ Seat post
Saddle: Rocker MTB 60°
Seatpost: Rockrider
Material: STEEL
Diameter: 27.2 mm
Length: 350 mm (S/M), 400mm (L), 450 mm (XL)
Tyres
Rockrider Fast 500
29 x 2.3
Tubeless Ready: No
Suspension
Fork: SR Suntour XCM32
Travel: 120 mm
Dampers: 32 mm
Axle: Quick Release
Format: 9x100 mm
Wheels
Rockrider 29"
Internal width: 23 mm
Number of spokes: 32
Disc mount: 6 holes
Freewheel hub: HG
Axle types: "QR", 9x100 mm at the front and 9x135 mm at the rear
Tubeless Ready: no
Equipped with a watertight rim base: No
ACCESSORIES INCLUDED
Your MTB comes with:
bell,
lights,
wheel reflectors
and pedals.
PEDALS
Btwin Sport 520 Grip flat pedals
Material:resin
Weight
S: 15.38 kg
M: 15.48 kg
L: 15.58 kg
XL: 15.78 kg
Net weight without pedals
FRAME
Composition: Aluminium
Travel: 120 mm Front
Rear axle: 9x135 mm
Type of axle: Quick Release
Bottom bracket: square
Seat tube diameter: 27.2 mm
Bottle cage mount: Yes (1 bottle)
Compatible with dropper seat post
TRANSMISSION
Microsoft drivetrain
Single chainring:30 teeth.
Cranks: 170 mm
Rear derailleur: 9 speeds
Cassette: 11-42
KMC Z9 chain: 112 LINKS
Riding position
Handlebar: Rockrider
Material: Aluminium
Diameter: 31.8 mm
Width: 740 mm
Rise: 25 mm
Stem: Rockrider
Material: Aluminium
Angle: 7 °
Size: 60 mm
Grips:
Sport 500
In a nutshell
Weight: 15.48 kg in size M (without pedals)
Frame material: Aluminium
Type: Hardtail
Wheel size: 29"
Fork travel: 120 mm
Drive train: 1x9
Brakes: hydraulic disc
Seat post: Fixed (dropper seat post compatible)
Warranty on the frame/2 years for the components
Brakes
Hydraulic disc brakes
Tektro M276
Number of pistons: 2
Front disc: 160 mm
Rear disc: 160 mm
Disc mount: 6 bolts
